The Sports & Wellness Category of Whitehall products contain a wide variety of sizes and shapes of hydrotherapy tanks, cold tanks, and turbines for use in a wide variety of settings and for specific purposes (treatment and prevention of sports related injuries) and targeted treatment areas. At ProHealthcareProducts.com we often get questions (and observations) from those seeking to purchase the best/most appropriate whirlpool tank or cold tank for their particular setting, desired recuperative purpose for use, and unique characteristics, such as size, of those individual(s) who will use the tanks.

Whirlpool Tank Design Configurations

Whitehall whirlpool tanks are fabricated of heavy-duty Type 304 stainless steel for superior strength and durability, and ease of cleaning and sanitizing.There are different design configurations in which the whirlpool tanks and cold tanks are designed to accommodate the unique settings and/or desires of the institution, organization, or individual that will be using the tanks. These are important to consider as they can impact the plumbing and space requirements of the facility where the tanks will be housed. They are:

Stationary Whirlpools

• Requires permeant plumbing connection
• Offers direct connection to drain and water supply
• Comes standard with high-capacity gravity drain

Stationary with Legs

• Uses permeant plumbing connection
• Provided with reversing turbines (standard) used to pump used water out of tank and into available sink/drain
• Legs are provided to give height to the whirlpool for easier under bottom cleaning

Stationary with Pedestal

• Simply elevates the whirlpool tank to a higher level for convenience and comfort in different seating settings

Mobile

• No special plumbing connection required
• Can use anywhere – reversing turbines (standard) pump used water out of tank and into available sink/drain
• Convenience of being able to be easily moved and positioned
• Smooth transport with heavy-duty locking casters

Mobile w/ Handle

• Simply provides a handle for easier moving of the whirlpool

Mobile w/ Undercarriage

• Simply provides greater clearance of tank so can be moved around easier over objects

Mobile w/ Lift Device

• Allows whirlpool tank to be elevated and lowered as needed

Whirlpool Tank Styles
In addition to the different design configurations, there are different styles of whirlpool tanks designed for targeted treatment areas of the body, different size individuals, and comfort accommodations as needed for different therapies. Whitehall Whirlpool Tanks can also be:

• “Customized” with team logos and color finish options with Enviro-Glaze. The Enviro-Glaze powder coat finish is a colorful alternative to the standard stainless steel ad bonds with the stainless steel to create a surface that is resistant to cracks, chips, and bubbles.

The different styles of whirlpool tanks are :

NOTE: When purchasing most Whitehall whirlpool tanks, you will select which “options” you will want with your tank. Those options are:

• Drain Options : Standard Drain or Separate Drain
• Plug Options : Standard or Ground Fault Interrupter
• Voltage Options: Standard 115V or 230 Volt (specify for European, United Kingdom, Australia, India, Israel)

Hydrotherapy (Whirlpool) Tanks – Podiatry

NOTE: Click the “Model Number” to view product page with photos and additional information

Hydrotherapy (Whirlpool) Tanks – Extremity

NOTE: Click the “Model Number” to view product page with photos and additional information

Hydrotherapy (Whirlpool) Tanks – Sports

NOTE: Click the “Model Number” to view product page with photos and additional information

Hydrotherapy (Whirlpool) Tanks – Hi-Boy

NOTE: Click the “Model Number” to view product page with photos and additional information

Hydrotherapy (Whirlpool) Tanks – Lo-Boy

NOTE: Click the “Model Number” to view product page with photos and additional information

Hydrotherapy (Whirlpool) Tanks – Slant Back

NOTE: Click the “Model Number” to view product page with photos and additional information

Hydrotherapy (Whirlpool) Tanks – Rectangular Full Emersion

NOTE: Click the “Model Number” to view product page with photos and additional information

Hydrotherapy (Whirlpool) Tanks – Hibbard Full Emersion

NOTE: Click the “Model Number” to view product page with photos and additional information

Cold water therapy has shown to be an effective therapeutic intervention in the treatment or prevention of exercise induced muscle damage (EIMD) and delayed onset muscle soreness (DOMS). As such, cold water therapy helps speed recovery from vigorous exercise for return to demanding physical activity and enhanced physical performance. Cold tanks are used in athletic training rooms at professional, collegiate, and high school levels, in wellness clinics, country clubs, and a variety of health promoting entities. And an increasing number of cold tanks are being purchased for home use by those seeking to enhance their personal wellness.

Cold Tanks (Stationary, Stationary w/ Legs, Mobile)
- Cold Tanks Sports

NOTE: Click the “Model Number” to view product page with photos and additional information

Cold Tanks (Stationary, Stationary w/ Legs, Mobile)
- Cold Tanks Hi-Boy

NOTE: Click the “Model Number” to view product page with photos and additional information

Model	Description (With Turbine)	Tank Dimensions	Treatment Area
WH-60-H-S-TO	Hi-Boy Cold Tank  • 60 Gallon  • Stationary	Length | 36 inches (915 mm) Width | 20 inches (510 mm) Depth | 28 inches (710 mm) Height | 33-1/2 inches (850 mm) Capacity | 60 Gallon (227.12 liters)	Lower Back, Hips, Lower Extremity
WH-60-H-M-TO	Hi-Boy Cold Tank  • 60 Gallon  • Mobile	Length | 36 inches (915 mm) Width | 20 inches (510 mm) Depth | 28 inches (710 mm) Height | 35 inches (890 mm) Capacity | 60 Gallons (227.12 liters)	Lower Back, Hips, Lower Extremity
WH-75-H-S-TO	Hi-Boy Cold Tank  • 75 Gallon  • Stationary	Length | 42 inches (1,065 mm) Width | 20 inches (510 mm) Depth | 28 inches (710 mm) Height | 33-1/2 inches (850 mm) Capacity | 75 Gallons (283.90 liters)	Lower Back, Hips, Lower Extremity
WH-75-H-M-TO	Hi-Boy Cold Tank 75 Gallon Mobile	Length | 42 inches (1,065 mm) Width | 20 inches (510 mm) Depth | 28 inches (710 mm) Height | 35 inches (890 mm) Capacity | 75 Gallons (283.90 liters)	Lower Back, Hips, Lower Extremity
WH-90-H-S-TO	Hi-Boy Cold Tank  • 90 Gallon  • Stationary	Length | 48 inches (1,220 mm) Width | 20 inches (510 mm) Depth | 28 inches (710 mm) Height | 33-1/2 inches (850 mm) Capacity | 90 Gallons (340.68 liters)	Below Shoulder, Back, Hips Lower Extremity
WH-90-H-M-TO	Hi-Boy Cold Tank  • 90 Gallon  • Mobile	Length | 48 inches (1,220 mm) Width | 20 inches (510 mm) Depth | 28 inches (710) mm) Height | 35 inches (890 mm) Capacity | 90 Gallons (340.68 liters)	Below Shoulder, Back, Hips Lower Extremity
WH-105-H-S-TO	Hi-Boy Cold Tank                                          • 105 Gallon  • Stationary	Length | 48 inches (1,220 mm) Width | 24 inches (610 mm) Depth | 28 inches (710 mm) Height | 33-1/2 inches (850 mm) Capacity | 105 Gallons (397.46 liters)	Lower Back, Hips, Lower Extremity
WH-105-H-M-TO	Hi-Boy Cold Tank  • 105 Gallon  • Mobile	Length | 48 inches (1,220 mm) Width | 24 inches (610 mm) Depth | 28 inches (710 mm) Height | 33-1/2 inches (850 mm) Capacity | 105 Gallons (397.46 liters)	Lower Back, Hips, Lower Extremity

  Cold Tanks (Stationary, Stationary w/ Legs, Mobile)
- Cold Tanks Lo-Boy

NOTE: Click the “Model Number” to view product page with photos and additional information

Model	Description (With Turbine)	Tank Dimensions	Treatment Area
WH-75-L-S-TO	Lo-Boy Cold Tank   • 75 Gallon   • Stationary	Length | 52 inches (1,320 mm) Width | 24 inches (610 mm) Depth | 18 inches (455 mm) Height | 24 inches (610 mm) Capacity | 75 Gallons (283.90 liters)	Below Shoulder, Back, Hips Lower Extremity
WH-75-L-M-TO	Lo-Boy Cold Tank 75 Gallon Mobile	Length | 52 inches (1,320 mm) Width | 24 inches (610 mm) Depth | 18 inches (455 mm) Height | 26 inches (660 mm) Capacity | 75 Gallons (283.90 liters)	Below Shoulder, Back, Hips Lower Extremity
WH-90-L-S-TO	Lo-Boy Cold Tank 90 Gallon Stationary	Length | 60 inches (1,525 mm) Width | 24 inches (610 mm) Depth | 18 inches (455 mm) Height | 24 inches (610 mm) Capacity | 90 Gallons (340.68 liters)	Below Shoulder, Back, Hips Lower Extremity
WH-90-L-M-TO	Lo-Boy Cold Tank 90 Gallon Mobile	Length | 60 inches (1,525 mm) Width | 24 inches (610 mm) Depth | 18 inches (455 mm) Height | 24 inches (610 mm) Capacity | 90 Gallons (340.68 liters)	Below Shoulder, Back, Hips Lower Extremity
WH-105-L-S-TO	Lo-Boy Cold Tank 105 Gallon Stationary	Length | 66 inches (1,675 mm) Width | 24 inches (610 mm) Depth | 18 inches (455 mm) Height | 24 inches (610 mm) Capacity | 105 Gallons (397.46 liters)	Below Shoulder, Back, Hips Lower Extremity
WH-105-L-SL-TO	Lo-Boy Cold Tank 105 Gallon Stationary W/ Legs	Length | 66 inches (1,675 mm) Width | 24 inches (610 mm) Depth | 18 inches (455 mm) Height | 27 inches (685 mm) Capacity | 105 Gallons (387 liters)	Below Shoulder, Back, Hips Lower Extremity
WH-105-L-M-TO	Lo-Boy Cold Tank 105 Gallon Mobile	Length | 66 inches (1,675 mm) Width | 25 inches (635 mm) Depth | 18 inches (710 mm) Height | 25 inches (635 mm) Capacity | 105 Gallons (397.46 liters)	Below Shoulder, Back, Hips Lower Extremity

The turbine for a whirlpool agitates the water, providing a mechanical massage effect to the body part being treated. The turbine also is used to facilitate draining of the water from the whirlpool.

The Whitehall Turbine Assembly is equipped with Underwriters Laboratory listed 1/2 HP jet pump motor protected with an ABS plastic shell, automatic thermal overload protector, and lifetime-sealed bearings. All parts contacting the water are stainless steel, chrome-plated brass or bronze.

• Stationary Whirlpools are provided with aerator cap. Stationary turbines provide agitation but do not reverse to evacuate water
• Mobile and Legs Whirlpools are provided with turbine pump-out hose assembly to empty whirlpool
• Provides vertical adjustment of height and direction of agitation
• Turbine electrical cord length is 9’ 8”. This determines the limit as to where you can move a mobile tank to
• Through certification from Nemko, the turbine meets US & Canadian Medical Standards UL 60601-1 & CSA C22.2 No. 601.1 and European Standards IEC 60601-1. Turbines operating with 115 Volts require 6.9 Amps 50 Hertz or 6.2 Amps 60 Hertz. Turbines operating with 230 Volts require 3.5 Amps 50 Hertz or 3.1 Amps 60 Hertz. Cord Type of European, United Kingdom, Australia, India or Israel must be specified for 230 Volts.

Hydrotherapy (Whirlpool) Turbines

NOTE: Click the “Model Number” to view product page with photos and additional information

More coming Soon...
